Hospital tilt bed

Description：

Hospital tilt bed mainly used in the nervous system out of control caused by weakness, pain, spasm of patients, auxiliary training to rehabilitation purposes; hemiplegia, paraplegia and traumatic brain injury and other severe patients to resume standing training.

It provides -2° tilting, adds to be used to diagnose dysautonomia or syncope,

It can also be used for long-term bedridden patients, to prevent the rise of orthostatic hypotension.

The Hospital tilt bed is also used in the area of functional rehabilitation for the handicapped and disabled patient.

The Operation video: https://youtu.be/n2mhKWqdWrs

Standard Specification：

1. One electric motor, standard supports "Timotion" brands for tilting function.

2. Hospital tilt bed with the table frame fixed height is 51cm.

3. Hospital tilt bed can adjustable the tilting function by hand switch.

4. Tilting up from 0° to +85° in approx 30 seconds by hand switch.

5. Tilting down from +85° to 0° in approx 30 seconds by hand switch.

6. Adjustable tiling featuring one electric motor, angle adjustable from 0° to +85°.

7. Accessories: adjustable belts(3 pcs), adjustable foot plate, active table adjustable, face hole.

8. Hospital tilt bed Able to lift up to 250kgs working weight from its lowest height.

9. Brake castors 125mm for excellent mobility and safety.

10. Hospital tilt bed sleek design with four rounded frame legs for safety.

11. Fire/stain/mildew/oil/water/wear resistant Med PVC available in 6 kinds of colors.

12. Certificates: CE, FDA, ISO13485-2016, EN60601.

Standard Options：

1. Contact us for more available optional.

Dimensions：

Table Length: 190cm

Upholstery Width: 64cm

Height: 51cm

Foam Thickness: 5cm

Foam Density: 36g/m2

Open: 190 x 64 x 51cm

Packing: 215 x 91 x 59cm

N.W./G.W.: 80/100kgs

20"GP/40"HC: 24/65pcs

20GP/40GP: 34/68pcs

Hospital tilt bed Size picture：
