Electric physiotherapy table
- COINFYCARE
- CHINA
- 30-40 days
- 1000 pcs
- EL02
This Electric physiotherapy table addresses the requirements of a wide range of manual handling issues to benefit both patient and doctor.
Description：
EL series Electric physiotherapy table is designed from our 10 years manufactures and 5 years electric tables’ manufactures. We are honest to say those excellent tables are leading items of whole worlds.
This Electric physiotherapy table has a very strong table designed to withstand constant heavy use with minimal maintenance.
This Electric physiotherapy table addresses the requirements of a wide range of manual handling issues to benefit both patient and doctor.
Youtube video link: https://youtu.be/v-KFYZdoHKs
Foot bar system operation video: https://youtu.be/H2it1pJYseI
The operation video: https://youtu.be/DL57pe3EJqU
Electric physiotherapy table EL02 upholstery intallation: https://youtu.be/BgRxN57td4s
Standard Specification：
1. One electric motor, standard supports "Timotion" brand for Hi-Lo function.
2. Height control from 46cm to 90cm in approx 30 seconds by footbar system.
3. Adjustable backrest featuring double gas struts, angle adjustable from -20° to + 70°.
4. Able to lift up to 250kgs working weight from its lowest height.
5. Retractable castors 75mm for excellent mobility and safety.
6. Electric physiotherapy table sleek design with two rounded frame legs for safety.
7. Adjustable feet on four frame legs work for uneven surfaces.
8. Fire/stain/mildew/oil/water/wear resistant Med PVC available in 6 kinds of colors.
9. Certificates: CE, FDA, ISO13485-2016, EN60601.
Standard Options：
1. Electric physiotherapy table EL02F: Foot Switch.
2. Extra 2cm foam thickness for upholstery.
3. Hand switch is available.
4. Paper roll holder is available
5. Fold-down Side Support (Pair)
6. Contact us for more available optional.
Dimensions：
Upholstery Length: 195cm
Back Section Length: 67cm
Body Section Length: 123cm
Upholstery Width: 66cm
Adjustable Height: 46cm – 90cm
Foam Thickness: 5cm
Foam Density: 36g/m2
Open: 195 x 66 x (46-90) cm
Packing: 200 x 72 x 51cm (Heavy carton)
N.W./G.W.: 60/73kgs
20GP/40GP:32/72pcs
Electric physiotherapy table Size picture:
