Electric gynecological table

Description：

This Electric gynecological table adds a extra extension at EL36 item, more comfortable for leg rest. It provides an extra function, same as a useful examination table.

The Electric gynecological table use dual Taiwan professional medical DC motor putter, low noise, stability and strong. Use For gynecological examination, liver and intestine examination and so on.

Youtube video link: https://youtu.be/oZnJrCE_r8Q

Operation video: https://youtu.be/OJtXoOhqLXw

Standard Specification：

1. Two electric motors, standard support "Timotion" brands for Hi-Lo & middle lifting.

2. Lift for height variation by footbar system and middle section by foot switch.

3. Height control from 62cm to 104cm in approx 30 seconds by footbar system.

4. Adjustable backrest featuring double gas struts, angle adjustable from 0° to +65°.

5. Adjustable seat section featuring one motor, angle adjustable from 0° to +20°.

6. Adjustable Up and down side rails (pair) to protect patients.

7. Accessories: Up and down side rails, Stainless steel plate, leg supports, Extra extension

8. Electric gynecological table able to lift up to 250kgs working weight from its lowest height.

9. Brake castors 75mm for excellent mobility and safety.

10. Electric gynecological table sleek design with four rounded frame legs for safety.

11. Adjustable feet on two frame legs work for uneven surfaces.

12. Fire/stain/mildew/oil/water/wear resistant Med PVC available in 6 kinds of colors.

13. Certificates: CE, FDA, ISO13485-2016, EN60601.

Standard Options：

1. Extra 2cm foam thickness for upholstery.

2. Hand switch is available.

3. Paper roll holder is available

4. Contact us for more available optional.

Dimensions：

Upholstery Length: 185cm

Backrest Length: 91cm

Seat Section Length: 46.5cm

Extra extension Length: 42.5cm

Upholstery Width: 60cm

Adjustable Height: 62cm–104cm

Foam Thickness: 5cm

Foam Density: 36g/m2

Open: 185 x 60 x (62-104)cm

Packing: 149 x 74 x 69cm (Heavy carton)

N.W./G.W.: 79/90kgs

20GP/40GP: 36/72pcs

Electric gynecological table Size picture：
